Inorax-16 Outdoor Cabinet

This outdoor cabinet is an ideal small size solution for any 19” active equipment installation and a perfect fiber cross connect cabinet for FTTX applications.

Description

Inorax-16 Outdoor Cabinet

This outdoor cabinet is an ideal small size solution for any 19” active equipment installation and a perfect fiber cross connect cabinet for FTTX applications.

Highlights:

  • Weather-proof outdoor cabinet for installation of 19” active equipment and optical distribution modules
  • Assembly of modular optical building blocks like splice, patch and splitter modules
  • Provides a secure anchor for incoming loose tube cables within the cabinet
  • Easy installation and removal
  • Doors are protected from external access through hidden hinges
  • High resistivity against corrosion
  • 1 pair of 19 inch mounting rails (Optional 2 pairs)
  • Single front door
  • CNC controlled polyurethane (PUR) gasketing is available for all of the complete openable surfaces of the outdoor to provide IP65 protection degree, which is complying with the EN6O529 standard
  • 1,5 mm mounting plate for cable management on the back side
  • C-rail for fixing cables on the back side
  • Optional:
    -Double front door,
    -Aluminum material

Technical Details:

  • Material: Single layer galvanized steel – 2 mm
  • Protection Level:  IP65
  • Plinth: 250 mm (H) plinth is included in standard configuration
  • Finish: Epoxy polyester outdoor paint, RAL 7035
